2inch Aodd Pvdf Pump

Get a Price/Quote

MOQ : 1 Unit

2inch Aodd Pvdf Pump Specification

Frequency
Not Applicable (Pneumatic)

Discharge Pressure
Up to 7 bar

Caliber
2 inch (50 mm)

Voltage
Not Applicable (Pneumatic operated)

Inlet/Outlet
2 inch BSP/NPT Threaded or Flanged

Speed
Variable - Depends on air supply

Noise Level
Below 85 dB

Flow Rate
Up to 6000 LPH (liters per hour)

Theory
Diaphragm Pump (Air Operated Double Diaphragm)

Control System
Manual/Pneumatic Controls

Working Temperature
Up to 80C

Max Suction
4-5 meters (dry lift)

Mounting Type
Floor mounted, Skid mounted

Head Size
Up to 70 meters

Features
Corrosion resistant, leak proof, dry running capability

Material
PVDF (Polyvinylidene Fluoride)

Structure
Double Diaphragm, Bolted Construction

Power
Compressed Air Driven

Standard
CE, ISO 9001:2015

Fuel Type
Compressed Air

Pressure
Maximum 100 PSI (7 bar)

Usage
Chemicals, Acids, Solvents, Wastewater, Corrosive Fluids

Application
Industrial, Chemical Processing, Effluent Treatment, Pharmaceuticals

Suction Type
Self-priming, positive suction

Seals Type
PTFE (Polytetrafluoroethylene)

Priming
Self-priming

Pump Type
AODD (Air Operated Double Diaphragm)

Capacity
Up to 100 LPM (liters per minute)

Serviceability
Easy maintenance with bolted construction

Check Valve Type
Ball-type

Wetted Parts
PVDF, PTFE

Leakage
Zero leakage design

Air Inlet Connection
1/2 inch BSP/NPT

Max Particle Size
Up to 6 mm

Body Finish
Smooth, anti-corrosive coating

Max Air Consumption
3400 LPH at max output

Port Orientation
Side entry/exit, customizable

Fluid Viscosity Range
Up to 5000 cps

Ball/Valve Material
PTFE or EPDM

Net Weight
Approx. 28-33 kg

Diaphragm Material
PTFE (Teflon) or Santoprene (optional)

Installation Orientation
Horizontal

Cycle Rate
Variable, up to 300 cycles/min

2inch Aodd Pvdf Pump Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
10 Days

About 2inch Aodd Pvdf Pump

Experience the latest in fluid handling innovation with the valorous 2-inch AODD PVDF Pump-a phenomenal solution available on exclusive promotion. This brilliant device boasts a bargain blend of durability and performance, constructed with a robust PVDF body, leak-proof PTFE or Santoprene diaphragm options, and anti-corrosive finish. With self-priming capabilities, zero-leakage design, and the flexibility to handle corrosive fluids, solvents, and wastewater, it is a must-have for industrial applications. Engineered for easy maintenance, variable output, and precise control, this pump sets a new standard for operational excellence.

Exceptional Industrial Performance & Durable Material Features

The 2-inch AODD PVDF Pump is engineered for challenging commercial environments, excelling in chemical processing, wastewater management, and pharmaceuticals. Manufactured from high-grade PVDF and PTFE materials, its superior corrosion resistance ensures remarkable operational longevity and reliability. Competitive advantages include a sophisticated anti-corrosive finish, zero-leakage bolted construction, and customizable side port orientations. Self-priming and dry-running capabilities further assure efficient, hassle-free fluid handling for demanding industrial requirements.

Certifications, Export Supply & Sample Availability for Global Markets

Our 2-inch AODD PVDF Pump is certified with CE and ISO 9001:2015, upholding rigorous quality standards. With ready freight options and shipment from India's major FOB ports, we ensure smooth supply chains for both domestic and export markets. To streamline your procurement process and instill confidence, sample units are available on request. We prioritize efficient packaging and careful handling to guarantee your pump arrives safely and promptly, supporting global business expansions.

FAQ's of 2inch Aodd Pvdf Pump:

Q: How does the 2-inch AODD PVDF Pump ensure leak-free operation?

A: The pump utilizes a robust bolted construction and PTFE seals, effectively eliminating leakage and ensuring safe handling of corrosive and hazardous fluids.

Q: What industries benefit most from the 2-inch AODD PVDF Pump?

A: Industries such as chemical processing, pharmaceuticals, effluent treatment, and wastewater management benefit greatly due to the pump's corrosion resistance and versatility.

Q: How can I maintain or service the 2-inch AODD PVDF Pump?

A: The pump is designed for easy maintenance with a bolted structure, allowing quick disassembly and reassembly. Routine checks and seal replacements keep it running optimally.

Q: What certification standards does this pump meet?

A: It holds CE and ISO 9001:2015 certifications, ensuring international quality compliance and reliability for industrial operations.

Q: Where does your company ship the 2-inch AODD PVDF Pump from, and can I request a sample?

A: Our pumps are shipped from major Indian FOB ports. Yes, sample units are available upon request to facilitate evaluation before bulk orders.

Q: What are the main material features of the AODD PVDF Pump?

A: Constructed with PVDF and PTFE, the pump showcases superior chemical resistance, a smooth anti-corrosive finish, and durability under harsh industrial conditions.
